Specifications:

Total Power: 3200W

Top heater: 800W

Bottom heater: 2400W

Power: AC220V±10?  50/60Hz

Dimensions: L390×W500×H580 mm

Positioning: V-groove, PCB support can be adjusted in any direction with exernal universal fixtureTemperature control: K Sensor   Closed loop

Temp accuracy: ±2?

PCB size: Max 400×350 mm Min 22×22 mm

BGA chip: 2X2-80X80mm

Minimum chip spacing: 0.15mm

External Temperature Sensor: one optional

Net weight: 40kgs

Main Functions :

? Uses LED monitor control – all the data adjustments, control and display are digitally presented in a clear and convenient fashion.

?This machine uses dual temperature control with wind heating for the upper part and IR heating for the lower part. Heating time, temperature and all relevant data are all displayed on the monitor.

?It uses precise K-type close circuit control and automatic temperature adjustment system, with temperature module to enable precision temperature control of ±2 degC. External temperature sensor enables temperature monitoring and accurate analysis of real time temperature profile.

? V-groove PCB support for rapid, convenience and accurate positioning that fits for all kinds of PCB board.

? Flexible and convenient removable fixture on the PCB board which protects and prevent damage to PCB. It can also adapt to rework various BGA packages.

? Various sizes of BGA nozzles, which can be adjusted 360 degree for easy installation and replacement;

? 6 segment temperature up (down)+6 segment constant temperature control

? Before the completion of uninstalling or welding, voice reminder / warning to get the workers prepared. After uninstalling or welding After uninstalling or welding, high capacity horizontal airflow fan manually or automatically cools down PCB to prevent PCB deformation and ensure quality of welding.

? CE certification, with emergency switch and automatic power-off protection device when emergency happens
