Details
Model Name
|
Color
|
Length (m)
|
LED QTY
|
LED type
|
WL(nm) / CT(K)
|
Lumen (LM)
|
View angle (Degree)
|
Voltage (V DC)
|
Current (A)
|
Power (W)
|
3528-R60
|
Red
|
5m
|
300
|
SMD 3528
|
625±2.5
|
/
|
120
|
12V
|
2A
|
24W
|
3528-G60
|
Green
|
5m
|
300
|
SMD 3528
|
525±2.5
|
/
|
120
|
12V
|
2A
|
24W
|
3528-B60
|
Blue
|
5m
|
300
|
SMD 3528
|
470±2.5
|
/
|
120
|
12V
|
2A
|
24W
|
3528-Y60
|
Yellow
|
5m
|
300
|
SMD 3528
|
590±2.5
|
/
|
120
|
12V
|
2A
|
24W
|
3528-W60
|
White
|
5m
|
300
|
SMD 3528
|
6000-8000
|
5-6LM
/chip
|
120
|
12V
|
2A
|
24W
|
3528-WW60
|
Warm White
|
5m
|
300
|
SMD 3528
|
3000-4000
|
4-5LM
/chip
|
120
|
12V
|
2A
|
24W
|
Above products are non-waterproof (IP33)
Features
Color: red, green, blue, white, warm white, yellow
Continuous length flexible led strips 5m/reel, cuttable every 3 LEDs
Runs on 12V systems
Super bright top LED
Solid state, high shock or vibration-resistant
Major reduction in power costs
120 degrees beam angle illumination
No RF interference
Maintenance free, easy installation
Long lifespan: 30,000 to 50,000 hours
Low power consumption and high intensity
Less 1% attenuation after 3,000 hours
CE & ROHS approved
Application of led ribbon tape
LED ribbon tapes are suitable for the following.
Decorative lighting for holiday, event, show, exhibition
Architectural lighting for canopy, corridor, window, archway
Emergency lighting
Auditorium walkway lighting
Stairway lighting
Backlighting for signage
Channel letter lighting
DIY lights for home use
Caution:
1. Pulling power lines and collision is prohibited to avoid damaging LED light.
2. Each 5-meters-long lamp must be connected to the main power supply.
3. All powers should be connected each other.
4. Please don't fold or twist below 60mm diameters to avoid fracture or lamp beads damage.
5. Be careful when power is on.
6. 20% power should be remained for lighting.
7. It is suggested to be installed under appropriate condition.
8. Positive and negative should be output in right way.
