| Parameter(english) |
| Main CPU | MST786 A9 dual core 1Ghz |
| RAM Memory | DDR3 1G |
| iNand Memory | 8GB |
| MCU IC | STM8AH6189 |
| Power IC model | TDA7560 |
| Bluetooth Modulator | BC6 |
| TV turner Model | QSD |
| Radio Turner Model | NXP6624 |
| Decoder IC | SUNPLUS 8202TQ |
| Main System |
| Video decoding performance | All format decoding |
| OS | android 4.2.2 |
| Boot Time | Basic application boot 16s,many android application boot 25s |
| Operation Temperature | -20°C +70°C |
| Storage Temperature | -30°C +80°C |
| Operation Current | Noemal 500 mA @ 4.2V |
| Voltage Input | 4.0~4.5V |
| Sleep Current | <15 mA |
| GPS |
| Map | Stored in memory or via SD card |
| Map Formate Support | Google map online,Sygic,Papago,3D maps,etc |
| Navigation Software Storage | Support SD/MMC/SDHC (Max for SDHC 4GB~32GB) |
| New Features | Suuport radio/disc/bluetooth/IPOD/IPHONE/SD playback while navigating |
| Voice | Yes |
| Display |
| Touch Screen | Capacitive touch screen |
| Screen Resolution | 1024*600 |
| Wall Paper | Live wallpaper |
| Drag the icon | Yes |
| UI Interface | 3D Interface |
| Language |
| Main Interface Language | English,Russian,French,German,Spanish,Italian,Arabic,etc.20 kinds of language |
| GPS Console Language | The actual voice and display language depend on GPS software while being used |
| Internat |
| 3G | Support 3G WCDMA or via phone as WIFI hot spot |
| WIFI | built-in |
| Application |
| File Movement | Support copy and move files among different storage media and profiles |
| Delete file | Yes |
| Install Android Application by File | Yes |
| Main functions | Support download,install and delete android apps |
| Desktop Applications | Weather,Live wallpaper |
| Input Method | Google,sougou,perpetual calendar,google translator and etc. |
| Communication | MSN, Skype, Gmail, Twitter, Facebook, QQ, blogs and etc |
| 3D Games | Plants V.S.Zombies,Save the birds,Fruit Ninja and etc. |
| Video/Audio |
| Video Format Support | Support full video format |
| Audio Format Support | Support full audio format |
| Video input | BT.656 input |
| Video output | 24bit digital output |
| Audio output | IIS |
| Audio input | IIS |
| EQ | Support pop,jazz,dance,classic,rock,normal,customized mode,treble/fade/bass/balance,loudness |
| Max audio output | 50W x 4 |
| Signal-To-Noise Ration | >90db |
| Disc |
| Media Format Support | MP3, WMA, MPEG1/2/4, JPEG, DivX, XviD,CD-DA,CD-TEXT |
| Regional | Regional decoding choice |
| Play the breakpoint memory | Yes |
| TV |
| Analog TV | Built-in |
| Digital TV | DVB-T(MPEG4), ATSC, ISDB-T,CMMB and etc(optional) |
| FM/AM Radio |
| AM Frequency Range | 522-1620KHz(China),522-1620KHz(Europe),530-1710KHz(America),522-1620KHz(Russian),18 stations |
| FM Tuning Range | 87.5-108MHz(China),87.5-108MHz(Europe), 87.5-107.9MHz (America),65-108MHz(Russian),36 stations |
| RDS | Yes |
| Bluetooth |
| Support Format | HFP,A2DP,AVRCP |
| Main Functions | Handsfree optional,phone music playback,auto swith when receiving calls,volume control,touchscreen keyboard,mute |
| Phonebook Search | Support search by name from A-Z |
| IPOD Function |
| Main functions | Iphone/ ipad ipod audio playback |
| Display | Song list,Artist,album,genres and composer |
| IPOD USB | Support IPOD USB,Support USB to read all phone files |
| Additional Features |
| DVR | Support independent driving record function,not effect all function of reception,such as DVD avx |
| Video OUT Function | CPU image can used as blackground video output |
| Parking Rearview Camera | Autoswitch in 3 seconds when parking(power off),Autio switch in o seconds when parking.(power on) |
| Steering wheel control | 20 virtual keys setup |
| Can control | Automotive status display(temperature,fan,belts,wipe the blade,door clsoed and etc. |
| USB/SD card connector | USB/SD (MAX 32GB or <1500 files) |
| usb1.0 connector,Support Samsung,blackberry,HTC,Motorala and etc. |
