All Truck Steel Wheel 22.5 (22.5X11.75 22.5X14.00 22.5X16.00)

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Price:

Min. order:150 Pieces

Trade Terms:FOB

Payment Terms:L/C, T/T

Trademark:GAMA

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:22.5X11.75 22.5X14.00 22.5X16.00

Material:Steel

Type:Wheel Hub

Drive Wheel:4WD

Wheel Hub Diameter:21-24"

Finishing:Cathodc Electrodephoretic Coating

Wheel Accessories:Wheel Spoke

Certification:ISO

Color:Siliver, White, Grey etc

Certificate:Inmetro Soncap ISO9000 Ts16949

Export Markets:Global

Additional Info.

Trademark:GAMA

Packing:Plastic Paper or Pallet or Bulk

Standard:INMETRO

Origin:Shandong China

HS Code:870870

Production Capacity:1, 000, 000 PCS/Year

Product Description

Technical characteristics of tubeless wheels
1. Rim, spoke wheels with high-strength special steel, bearing capacity, impact resistance, no deformation.
2. Spinning machines imported from Germany, high precision, spoke uniform thickness, excellent dynamic balance.
3. Using the world's most advanced submerged arc welding process, welding uniform, solid, beautiful.
4. Wheel rim welding using the world's popular flash butt welding techniques, weld trace, does not leak.
5. Cathodic electrophoretic paint process to prevent the wheels rust; Plus finish, beautiful appearance.
6. The unique design of the large arc rim to protect the tires toe mouth, not born out.
7. Both the scientific design of the wind hole to ensure good heat dissipation of the wheels, spokes and ensures high strength.

Tubeless Wheel Size:
11.75x22.5
9.75x22.5
9.00x22.5
8.25x24.5
8.25x22.5
8.25x19.5
7.50x19, 5
6.75x19.5
6.75x17.5
6.00x17.5
5.25x17.5

Tube Wheel Size:
8.50-24
8.50-20
8.00-20
7.50-20
7.00-20
6.50-20
6.50-16
6.00G-16
5.50F-16

ALL SIZE OF TRUCK STEEL WHEEL AVAILABLE. AND ALL THE PAREMETERS CAN BE CHANGED AS YOUR REQUIRED.
SHOULD YOU HAVE ANY QUESTIONS, PLS DO NOT HESITATE TO LET ME KNOW.

22.5x14.00	No. of Bolt Holes	Bolt Hole DIA.	Bolt Hole Type	P.C.D.	C.B.D.	Offset	Tyre Size
1	8	32.5	SR22	275	214	0	18 R 22.5 425/65 R 22.5 445/65 R 22.5 445/75 R 22.5
2	8	32.5	SR22	285	221	0
3	8	26	1X45°	275	221	0
4	8	21.5	SR16	275	221	60
5	10	26	1X45°	285.75	220	60
6	10	32.5	SR22	285.75	221	75
7	10	27	SR18	335	281	120
8	10	26	1X45°	335	281	120
