Alloy Steel Stainless Steel Set Screw Dog Point

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Price:$0.007 - $0.009 / Piece

Min. Order (Pieces)	Unit Price
10000.0	US $ 0.009/ Piece
100000.0	US $ 0.007/ Piece

Trade Terms: FOB, CFR, CIF

Payment Terms: L/C, T/T, Western Union

Price Valid Time:From Mar 11, 2015 To Jun 11, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:LKYI

Material:Stainless Steel, Alloy Steel, Steel, Brass

Type:Hex Socket Head

Groove:No

Connection:Common Bolt

Head Style:Headless

Standard:DIN, GB, BSW, JIS

Grade:Class 10.9, 12.9, Grade 8; A2, A4

Market:Global

Sample:Free (If in Store)

Additional Info.

Trademark:LK

Packing:Bulk packing, Small Box

Standard:DIN, ANSI, ISO and Non-Standard

Origin:China

HS Code:7318

Production Capacity:500 Ton/Month

Product Description

Alloy Steel Stainless Steel Set Screw Dog point
1> Decription: Alloy Steel Stainless Steel Set Screw Dog point
2> Material: Alloy Steel, stainless steel
3> Surface: Plain, Zinc plated, Passivate
4> Size: #10-3/4, M2-M20
5> Length: Up to 150mm
6> Mechanical Properties: Class 10.9, 12.9, Grade 8; A2, A4
7> Packing: Bulk packing and box packing

The set screw include, but not only
DIN913 Hex. Socket Set Screw with Flat point
DIN914 Hex. Socket Set Screw with Cone Point
DIN915 Hex. Socket Set Screw with Dog Point
DIN916 Hex. Socket Set Screw With Cup Point
ASME B18.3 Set Screw
Please feel free to contact us if you are interesting our products. We are strongly believe will guarantee you the best quality and service for our more than 30 years professional experience.

Technical Delivery Conditions
Material		Steel	Stainless steel		Non-ferrous metal
General requirements		As specified in DIN 267 part 1
Thread	Tolerance	5g / 6g
	Standard	DIN13 Part 12 & 15
Mechanical properties	Property class	45H	?M20	A2-70	Subject to agreement
				A4-70
			>M20	A2-50
				A4-50
	Standard	ISO 898 Part 1	ISO 3605, DIN267 Part 11		DIN267 Part 18
Limit deviations geometrical tolerance	Product grade	A

	Standard	ISO 4759 Part 1
Surface finish		Black Oxide	Bright		Bright
		DIN267 Part 2 shall apply with regard to surface roughness
		DIN267 Part 9 shall apply with regard to electropiating
Acceptance inspection		DIN267 Part 5 shall apply with regard to acceptance inspection
