Cabin Shock Absorber for Mercedes-Benz Axor 1823 - 2044 Truck Cabin Shock Absorber

Live chat with Seller

If you want to live chat with Seller ,Please - LOGIN to View Links.

Cabin Shock Absorber for Mercedes-Benz Axor 1823 - 2044 Truck Cabin Shock Absorber

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Pieces)	Unit Price
100.0	US $ 0.1/ Piece

Price:US $0.1 / Piece

Trade Terms: FOB, CIF

Payment Terms: L/C, T/T, Western Union

Price Valid Time:From Jul 06, 2015 To Sep 17, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:942 890 05 19 958 317 07 03 375 890 04 19

Part:Dampers

Position:Front

Type:Gas-Filled

Spring Type:Coil Spring

Spring Material:Steel

Structure:Double Cylinder

Application:Mercedes-Benz

Brand:Gerep

Damping Force Direction:Single Effect

Categories:Auto Spare Parts

Products:Shock Absorber

Location:Zhejiang, China

Painting Color:Customized Color Is Available

Painting Style:Shining or Matte

Packing Box:Customized Color Is Available

Engrave:Customized Design Is Available

Delivery Date:45~60 Days

Transportation:by Sea, Train or Air

Quality Guarantee:30000 Kms

Export Markets:Global

Additional Info.

Trademark:GEREP

Packing:Gerep Color Package and Customized Package.

Standard:TS/SGS 16949

Origin:Zhejiang

HS Code:870880100

Production Capacity:50000 PCS/Month

Product Description

TECHNOLOGY INTRODUCTION:

S/N.	Material speciation	Top quality
1	Piston Rod	The piston rod, larger in diameter to increase the strength, is hard-chrome plated, induction hardening , and fine polished for greater resistance to corrosion, thus, assuring of smooth action.
2	Oil Seal	The special Multi-slip oil seal, made of oil and wear-resistant high quality synthetic rubber, having high sealing efficiency to keep vital oil and gas in and dirt out of the cylinder.
3	Rod Guide	The sintered iron rod guide with a PTFE-bushed sliding surface, assures smooth rod action with minimal resistance and wear.
4	Nitrogen Gas	Nitrogen gas is filled in the reservoir except hydraulic type shock absorbers.
5	Rebound Stopper	A rebound stopper, made of a high quality synthetic rubber, or resin, is installed on the piston rod to act as the rebound stop.
6	Pressure Tube	The pressure tube, with a precision sliding surface mirror-like finish is designed to withstand tremendous internal working pressures, thus, providing greater reliability.
7	Piston Valve	Unique automatic control rebound disc valve, which automatically adjusts to all ride conditions, is designed to assure maximum performance and smooth ride control.It also provides instant response for full performance without any time lag.
8	Absorber Oil	Our absorber oil with constant viscosity, blended with chemical additives provide optimum operating performance keeping its efficiency, in any weather conditions.
9	Bottom Valve	Compression disc valve, which provides excellent performance, has automatic control actions similar to the rebound piston disc valve.

TRADE CONDITION:

1. RFQ - Request for quotation

We could identify shock absorbers by OEM No. or other brands part number which list following ( KYB, TOKICO, SACHS. BOGE, Bilstein, AL-KO, KONI, SABO, WEBCO, RECORD, MONROE, Gabriel, Cofap, Corven, NAKATA, Ultima, etc. )

Please send RFQ to our email to know our latest prices.

2. MOQ - Minimum order quantity

Our MOQ is 100 Pcs for each item, but if there are few items that we have in stock, the MOQ will not be indicated.

3. Customized brand packing box

We could accept customerized brand packing box based on MOQ 3000 pcs. If customerized brand order quantity less than 3000 pcs, a extra charge for printing box will be added in commercial invoice.

4. Delivery time: 45~60 days.

5. Payment term: 1> L/C 2> T/T

CABIN SHOCK ABSORBER SUIT FOR MERCEDES-BENZ CABIN SERIES:

Application models for MERCEDES-BENZ truck cabin	Year	OEM
ACTROS 1831 - 1860	04.96 -	942 890 50 19 942 890 51 19 942 890 49 19 942 890 55 19
ACTROS 2031 - 2055	04.96 -	942 890 38 19 942 890 39 19 943 890 12 19 943 890 13 19 943 890 46 19
ACTROS 2531 - 2560	06.96 -	942 890 49 19 942 890 50 19 942 890 51 19 942 890 55 19
ACTROS 2631 - 2660	04.96 -	942 890 50 19 942 890 51 19 942 890 55 19 943 890 01 19 942 890 49 19
ACTROS 3231 - 3336	06.96 -	942 890 50 19 942 890 51 19 942 890 49 19 942 890 55 19
ACTROS 3340 - 3360	06.96 -	942 890 55 19 943 890 01 19 942 890 59 19 943 890 38 19
ACTROS 4140 - 4160	06.96 -	942 890 36 19 943 890 10 19 943 890 11 19 943 890 16 19 943 890 17 19 942 890 38 19 942 890 39 19 943 890 12 19 943 890 13 19 943 890 46 19
ATEGO 1823 - 2628		940 890 05 19 940 890 10 19 942 890 05 19 958 317 07 03
ATEGO 712 - 717 712-1528		970 317 06 03 970 317 38 03 970 317 46 03 958 317 05 03 970 317 17 03 970 317 41 03 958 317 06 03 970 317 18 03
ATEGO 812 - 824	01.98-10.04	958 317 05 03 970 317 17 03 970 317 41 03 958 317 06 03 970 317 18 03 970 317 42 03
ATEGO 915 - 925	01.98-10.04	958 317 05 03 970 317 17 03 970 317 41 03 958 317 06 03 970 317 18 03 970 317 42 03
ATEGO 1015 - 1024	01.98-10.04	940 890 03 19 970 317 27 03 970 317 37 03 970 317 45 03 958 317 05 03 970 317 17 03 970 317 41 03
ATEGO 1214 - 1229	01.98-10.04	958 317 06 03 970 317 18 03 970 317 42 03 958 317 03 03 970 317 29 03 970 317 39 03
ATEGO 1317 - 1329	01.98-10.04	958 317 05 03 970 317 17 03 970 317 41 03 958 317 06 03 970 317 18 03 970 317 42 03
ATEGO 1517 - 1725	01.98-10.04	958 317 05 03 970 317 17 03 970 317 41 03 958 317 06 03 970 317 18 03 970 317 42 03
ATEGO 1823 - 1929	01.98-10.04	940 890 05 19 940 890 10 19 375 890 08 19 940 890 45 19 940 890 46 19 958 317 15 03
ATEGO 2223 - 2528	01.98-10.04	970 317 01 03 970 317 30 03 970 317 31 03 970 317 32 03 970 317 50 03 940 890 02 19 970 317 26 03 970 317 36 03
ATEGO 2628 -	05.98-09.04	940 890 05 19 940 890 10 19 375 890 08 19 940 890 45 19 940 890 46 19 958 317 15 03
AXOR 1823 - 2044	01.02 -	942 890 05 19 958 317 07 03 375 890 04 19 375 890 09 19 940 890 38 19 940 890 47 19 958 317 10 03 958 317 11 03
AXOR 2436 - 2543	01.02 -	375 890 08 19 940 890 45 19 940 890 46 19 958 317 15 03 942 890 05 19 958 317 07 03
AXOR 2623 - 2831	09.01 -	942 890 05 19 958 317 07 03 375 890 04 19 375 890 09 19 940 890 38 19 940 890 47 19 958 317 10 03 958 317 11 03
AXOR 3228 - 4144	09.01 -	942 890 05 19 958 317 07 03 940 890 08 19 940 890 09 19 940 890 13 19 940 890 15 19
Unimog		003 323 52 00

COMPANY INTRODUCTION:

We,Zhejiang Gerep Automotive Parts MFG Co., Ltd.,is a professional shock absorber manufacture.We manufacture different kinds of shock absorber,which suit for passenger car,truck,off road,coilovers etc.We pursue high quality and reasonable price. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. To perfect our service, we provide the products with good quality at the reasonable price.

GEREP SHOCK ABSORBER - CREAT VALUE FOR CUSTOMER
