Description

Details

Basic Info.

Model NO.:WTM-80

Name:Electric Hydraulic Brake Shoe Riveting Machine

Power:Electric Hydraulic

Applicable Rivet Size:3-12mm

Export Markets:Global

Additional Info.

Trademark:Haolida

Packing:Export Plywood Case

Standard:ISO

Origin:China, Shandong

HS Code:8463900090

Production Capacity:500PCS Per Month

Product Description

WTM-80 Model Factory Supply Electric Hydraulic Brake Shoe Riveting Machine

General introduction:
It is used for riveting rivets of all kinds of brake shoes\brake disc\brake drum\brake lining \ brake pad and other auto parts.

Advantages:

1.It uses advanced electro-hydraulic principle.
2.It possesses large riveting force and functions of piercing & riveting various copper, aluminum and iron rivets.
3.It is suitable for heavy duty truck brake lingings,etc.
4.Pressure can be adjusted according to size and material of the rivets.
5.Good discount based on order quantity

Technical parameter:

Model no	WTM-80
Material	Metal plate
Painting	High quality paint
Color	Blue&black
Max rivet force	80KN(8T)
Suitable rivet diameter	3-12mm
Maximum center height	260mm
Maximum working stroke of oil cylinder	160mm
Riveting speed	stepless speed regulation
Accessories:
Riveters: 5pcs, used for working on ?3, ?4,?5,?6,?8,?10, ?12 rivets Puncher: 1pc, used to remove old rivets 3mm-12mm
Others you may want to know:
MOQ	1set
Warranty period	12 months
Payment term	T/T 100% in advance
Delivery time	10days after receiving downpayment
HS code	8463900090
Packing sizes	Export plywood case N.W:130KGS G.W:150KGS 7606101150mm=0.53CBM
20'' container	50pcs/90pcs

Why Choose us:

1.32 years' design,development and produce experience
2.Professional R&D team
3.Strict QC
4.A good pre-sale and after-sale service
5.Can design and make according to customer's requests
