Heavy Duty 40m3 54m3 56m3 60m3 LPG Tank Semi Trailers

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Pieces)	Unit Price
1.0	US $ 36800.0-39900.0/ Piece

Price:$36800.0 - $39900.0 / Piece

Trade Terms: FOB, CFR, CIF, DAT, FAS, DDP, DAP, CIP, CPT, FCA, EXW

Payment Terms: L/C, T/T, D/P, Paypal, Money Gram, Western Union

Price Valid Time:From Jul 14, 2015 To Oct 14, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:CLW

Function:Storage Pressure Vessel

Application:Liquefied Gas

Material:Carbon Steel

Pressure:1.6MPa?p<10.0MPa

Storage Medium:Flammable/Toxic

Pressure Level:Medium Pressure (1.6MPa?p<10.0MPa)

Condition:New

Volume of LPG Tanker:40000L to 58600L

Shape of End Plate:Ellipse or Round

Axle:3 Axles, BPW, Fuwa or L1 Brand

Filling Material:Propane/Propylene /Isobutane

Filling Coefficient:0.42ton/Cbm to 0.58ton/Cbm

Baffle:4-5 PCS Inside

Safety Control System:Safety Valve, Pressure Meter, Cut-off Valve

Color:as Optional

Tire:11r22.5 or 12r22.5 Tubeless

King Pin:Jost Brand, 50# or 90#

Export Markets:Global

Additional Info.

Trademark:CLW Brand

Packing:Naked Package and Waxed Before on Board

Standard:CCC, ISO 9001, TS

Origin:Hubei

HS Code:73110090

Production Capacity:800 Unit/Month

Product Description

China Best LPG manufacturer ,40m3 54m3 56m3 60m3 lpg tank semi trailer, lpg semi trailer, lpg propane tanker trailers

1,We have the biggest LPG truck capacity 35.5CBM.
2,We have the biggest LPG semi-trailer capacity 60CBM, low transportation cost,bring more profit.
3,We can also provide LPG storage tank ranged from 5CBM to 120CBM, both on ground ones and underground ones.

CLW functional characteristics of liquefied petroleum gas tank:
1, pressure components of the product materials, dimensions and weld quality, operation quality, installation quality,safety devices and accessories within the strict qualification
2, conventional tank materials on physical and chemical tests such as: mechanical properties and chemical composition.Their welded joints, weld, tank head, the pressure of the geometric location of each component through rigorous X-ray non- destructive testing and magnetic particle testing inspection.
3, seal on the product, pressure, and those who can affect the operation of product safety testing various technical indicators.
4, A,B Class 100% ray weld inspection, II level qualified, C, D Class welds 100% magnetic particle inspection, I level qualified.

Chengli Special Automobile Co., Ltd
1. We are a group company with one years quality guarantee.
2. We have advanced technology and equipments, mature experience.
3. We are leading manufacturer in China, the price of our trucks are competitive.
4. We have modern management system, the delivery time are on time.
5. We exports many trucks over the world. We have professional sales team.

If you are interested in our trucks, pls contact me, I will send our best quotation to you.

Contact person: Krystal Zhang
Tel: +86-15171412234

Item			Unit	Parameter
Product name				3 axle semi-trailer
Practical capacity			M3	45.3
Gross weight			kg	40000
Curb weight				16440
rated loading capacity				23560
Overall dimension			mm	1136024903980
Axle				3
Wheelbase				5100+1320+1320
Tread		Front tread		-
		Rear tread		1840/1840/1840
Front/rear suspension			mm	-/1745
Leaf spring				-7/7/7
Fifth wheel max loading			kg	16000
Tyre specification				12.00-20
Exclusive configuration	Tank material		Q345R
	Standard configuration		12T BPW axle, safety valve,single fluid two valve box.hydraulic legs,traction pin,liquid Indicator,pressure gauge,temperature gauge,emergency cut-off valve,valve box,fire suppression bottle,spark hider cover,anti static grounding tape,protective guard,tyre protective shield.
	Other		Filling Medium:liquid ammonia:design pressure 2.16Mpa,design temperature 50°C,filling ratio:0.52t/m3,corrosion allowance:1mm:dimension of tank:10924*2426mm .
	Standard configuration		GB150-1998<Steel pressure vessels>,Supervision regulation on safety technology for pressure vessel,Supervision regulation on safety technology for Liquefy gas tank truck.
