Hex Washer Head Self Drilling Screw Green Zinc

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Price:$0.007 - $0.009 / Piece

Min. Order (Pieces)	Unit Price
100000.0	US $ 0.009/ Piece
1000000.0	US $ 0.007/ Piece

Trade Terms: FOB, CFR, CIF

Payment Terms: L/C, T/T

Price Valid Time:From Jun 12, 2015 To Dec 31, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:LKDX

Material:Stainless Steel, Alloy Steel, Steel, Brass

Type:Hexagon Head

Groove:Phillips, Slotted, Pozi, Six-Lobe, Square......

Connection:Drilling

Head Style:Hexagonal

Standard:DIN, GB, ANSI, BSW, JIS

Grade:to Standard

Market:Global

Sample:Free (If in Store)

Additional Info.

Trademark:LK

Packing:Bulk Packing, Small Box Packing

Standard:DIN, ANSI, ISO, JIS and Non-Standard

Origin:China

HS Code:7318

Production Capacity:500 Ton/Month

Product Description

Hex Washer Head Self Drilling Screw Green Zinc
1> Description: Hex Washer Head Self Drilling Screw Green Zinc
2> Material: Stainless Steel, Alloy Steel, Steel, Brass
3> Surface: Zinc Plated, Painted.......Passicvated
4> Size: 2.5mm (#6) up to 6.3mm (#14)
5> Length: Up to 150mm (6 Inch)
6> Head style: Pan Head, Flat Head, Hex Head, Oval Head, Truss Head......
7> Drive size: Phillips, Slotted, Pozi, Six-lobe, Square......
8> Packing: Bulk packing, box packing & to customer's requested.

Lockey Industrial Produce the screw include Self Drilling Screw, Self Tapping Screw(Sheet Metal Screw), Drywall screw, Chipboard screw, Roof screw, machine screw, wood screw, plastic screw...

If you are interesting our products, please do not hesitate to contact us, then we could quote our best price as soon as get from you.

Technical Delivery Conditions
Material	Steel	Stainless steel
General requirements	As specified in DIN 267 part 1
Screw thread and thread ends	As specified in DIN 7970
Cross recesses	As specified in DIN 7962
Metallurgical properties	Surface hardness?560 HV 0.3	A2, A4
	Core hardness: 240-560 HV 0.3
Material	DIN 17200, DIN17210	A2, A4
Mechanical properties Test	As specified in DIN 50133 part 2, DIN50190 part 1
Limit deviations geometrical tolerance	Product grade A as specified in ISO 4759 part 1
	ISO 4759 Part 1
Surface finish	As processed	Bright
	DIN267 Part 2 shall apply with regard to surface roughness
	DIN267 Part 19 shall apply with regard to permissible surface discontinuities
	DIN267 Part 9 shall apply with regard to electropiating
	Other type of surface protaction being suject to agreement
Acceptance inspection	DIN267 Part 5 shall apply with regard to acceptance inspection
