High Quality Water Proof Sandwich Panel

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Price:$3.4 - $22.5 / Meter

Min. Order (Meter)	Unit Price
1000.0	US $ 3.4/ Meter
10000.0	US $ 22.5/ Meter

Trade Terms: FOB, CFR, CIF

Payment Terms: L/C, T/T

Price Valid Time:From Oct 23, 2014 To Dec 31, 2014

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Description

Details

Basic Info.

Model NO.:950mm, 9560mm, 1150mm

Material:Metal

Color:Blue

Export Markets:Global

Additional Info.

Trademark:Shengxin JKS

Packing:Seaworthy, as Customer?s Requirement

Standard:SGS BV

Origin:Xiamen, China

Production Capacity:10000meter/Month

Product Description

Product features:
The sandwich panels are new multi-purpose construction material.
1. Heat and sound insulation. Temperature suitable for PU ranges from -200 centigrade to 150 centigrade.
2. Light weight, water-proof, Good chemical resistance and seismic resistance, anti-corrosion etc.
3. Energy conservation, environment protection, economical, good structure, easy to installation.
High Quality Water Proof Sandwich Panel

Color Steel Foam sandwich panel
Type	color steel foam sandwich panel (overlap joint)
Dimensions	Total thickness	50-200mm
	Width	950mm 960mm 1150mm
	Length	Less than 11.8m
External face	Material	ppgi
	Thickness	0.18-0.6mm
	Thickness of the zinc	60g-80g/m2
	Corrosion protection	Galvanized
	Coating	Polyester
	Thickness of coating	20 micron
	Color	According to the RAL
	Pattern	Nearly plain
Insulation	Optional foam Material	EPS PU Rockwool Paper honeycomb
	Thickness	50-200mm
	Density	EPS 12~25KG/M3; PU 36-45KG/M3; ROCKWOOL>110KG/M3;
	Thermal conductivity	0.045w/m2k 0.021W/M2K 0.0034W/M2K0
Internal face	Material	ppgi
	thickness	0.18-0.6mm
	Thickness of zinc	60g-80g/m2
	Corrosion protection	Galvanized
	Coating	Polyester
	Thickness of coating	17/7micron
	Pattern	Plain
Shipping terms
Package	Craft paper or wooded pallet
Delivery time	Within 15-20days after deposit
application	Purification workshop condole top , Industrial workshop and warehouse
