XCMG Hydraulic Truck Crane with 25ton QY25E

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Price:

Min. order:1 Piece

Trade Terms:FOB, CIF

Payment Terms:L/C, T/T, Western Union

Trademark:XCMG

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:QY25E

Export Markets:Global

Additional Info.

Trademark:XCMG

Packing:Suitable Package for Shipment

Standard:CE, ISO9001

Origin:Jiangsu, China

Production Capacity:100sets/ Month

Product Description

XCMG Hydraulic truck crane with 25ton QY25E

Specifications

XCMG Truck Crane QY25E
1. Max. total rated lifting capacity: 25t
2. Max. load moment: 806KN/m
3. Total mass: 26400kg

QY25E Truck Crane is equipped with XZ25A truck crane special chassis and EuroIIcompliant D6114ZLQ5B/WD615.64 engine.
4-section telescopic boom, 1-section jib, double H-shaped outriggers and single cylinder for front support elevating. Boom is telescoped sequentially and synchronously. Main and auxiliary winches can be driven individually.
4-section telescopic boom is made of high-tensile steel with hexagonal boom profile, high strength and heavy load lifting capacity.
Hoist mechanism is double independent winches with two-stage planetary reducer, compact structure, smooth and reliable work. Swing system with double-way-sliding function enables the boom to slide automatically to position during lifting operation.
Single top and adjustable offset jib meet special need of operation on high building and narrow site.
Automatic load moment limiter (LML) and LCD indicator equipped can dynamically display the data of working radius, boom length, boom angle, actual lifting load, etc., and the function of overload warning ensures safe and reliable operation.
QY25E plateau type, optional for users in highland area, is suitable for special working environment of heavy wind and sand, lower temperature, rare air, etc.
XCMG Hydraulic Truck Crane with 25ton QY25E

Classificatory	Item		Unit	Parameter
Engine	Model		D6114ZLQ5B
Outline dimension	Overall length		mm	12380
	Overall width		mm	?2500
	Overall height		mm	3500
	Wheel base	Axle 1, Axle 2	mm	4025
	Wheel base	Axle 2, Axle 3	mm	1350
Mass	Total mass in travel state		kg	26400
	Axle load	Axle 1	kg	6530
	Axle load	Axle 2, Axle 3	kg	19870
Travel performance	Travel speed	Max. travel speed	km/h	?63
	Travel speed	Min. stable travel speed	km/h	?4
	Turning diameter	Min. turning diameter	m	?19
	Turning diameter	Min. turning diameter at boom tip	m	?22
	Min. ground clearance		mm	?273
	Approach angle		(°)	?21
	Departure angle		(°)	?10
	Braking distance (at 30km/h with full load)		m	?9.5
	Max. grade-ability		%	?23
	Fuel consumption for 100km		L	36
