Zoomlion 40 Ton Truck Crane QY40V532

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Pieces)	Unit Price
1.0	US $ 100000/ Piece

Price:US $100000.0 / Piece

Trade Terms: CIF

Payment Terms: L/C, T/T

Price Valid Time:From Dec 04, 2014 To Feb 23, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:QY40V532

Type:Small Crane

Application:Construction Usage

Certification:ISO9001: 2000, CE

Condition:New

Export Markets:Global

Additional Info.

Trademark:ZOOMLION

Packing:Nude

Standard:ISO

Origin:China

Product Description

The QY40V532 truck crane, which is developed independently to adapt to the market demands, is a new-generation and high-performance product integrating our company many years' manufacturing experience with advanced technologies. Its performances such as lifting height, boom length, working speed and lifting capacity have achieved advanced international level.

The truck crane, with spacious cab and luxurious equipments, adopts full slewing system, telescopic boom, hydraulic proportional control system and self-made full-width special purpose chassis with four axles. 8× 4 drive and hydraulic power steering mechanism provides the crane with good driving performance and flexible steering.

The system with latest load feedback hydraulic operated proportional directional control valve and quadruple gear pump, and the safety devices fitted in hydraulic system, such as relief valve, balance valve, hydraulic lock and brake valve etc., prevents the oil line from overloading and the accidents caused by oil pipe breakage to makes full use of the working capacity of each actuating mechanism. Thus the reliability and safety of the crane are increased.

The safety devices such as load moment limiter, and the complete lighting system equipped in the crane ensure your safety during operation and are convenient for night work.

This crane has a novel style which makes it beautiful in figure, in form and in color.
The imported engine with original packing has strong power, and can meet the requirements of high-efficient work.
- Precise matching design with advanced energy conservation control can reduce the oil consumption of the machine.
- Low emission meets the Europe II standard.
- The adoption of new cooling fan and large-scale silencer lowers the noise of the machine.
- The adoption of the advanced turbocharging technique increases the highland adaptability of the machine.
- Automatic preheating system improves the working capacity in the low temperature.
- Unique fan cover with the shape of hopper opening greatly improves the air supply of the engine and the radiating capacity of the system, guaranteeing the successive high-efficient work of the machine.
- Restart prevention system effectively avoids the misoperation, and improve the use security of the machine.

Item			Value	Remarks
Working performance specification	Max. rated total lifting capacity kg		40000
	Max. load moment of basic boomkN.m		1430
	Max. load moment with max. main boom lengthkN.m		800
	Max. lifting height of basic boomm		12.0
	Max. lifting height of main boomm		41.7	Deformation of boom is not taken into consideration.
	Max. lifting height of fly jibm		56.4
Working speed	Max. speed of single rope on main winchm/min		130	The 4 th layer of drum
	Max. speed of single rope onauxiliary winchm/min		80	The 2 nd layer of drum
	Derricking time of booms		40
	Telescopic time of booms		80
	Slewing speedr/min		0~2.2
Traveling specification	Max. traveling speedkm/h		70
	Max. gradeability%		30
	Min. turning circle diameterm		24
	Min. ground clearancemm		280
	Limits for exhaust pollutants and smoke		Comply with related standards	GB3847-2005 GB17691 -2005 (Stage III)
	Oil consumption per hundred kilometers L		48
Mass specification	Deadweight of crane in traveling conditionkg		37000
	Complete vehicle kerb masskg		36870
	Front axle loadkg		13700
	Rear axle loadkg		23300
Dimension specification	Overall dimensions (L×W×H)mm		13060×2750×3560
	Base on outriggers m		5.60
	Distance between outriggersm		6.90(fully)
	Main boom lengthm		10.9~41.0
	Main boom angle°		-2~80
	Fly jib lengthm		9 ,15
	Offset angle of fly jib°		0 , 30
Chassis	Model		ZLJ5414
	Class		II
	Engine	Model	WP10.290	QSL 325
		Rated powerkW/r/min	213/2200	242/2100
		Max. output torqueN.m/r/min	1160/1200~1600	1424/1500
	Manufacturer		Changsha Zoomlion Heavy Industry Science & Technology Development Co., Ltd.
