| Basic Functions | Range | Best Accuracy |
|---|
| DC Voltage Measurement | 40mV
400mV
4V/40V/400V
1000V | +/-(0.8%+3)
+/-(0.8%+3)
+/-(0.5%+1)
+/-(1%+3) |
|---|
| AC Voltage Measurement | 40mV
400mV
4V/40V/400V
750V | +/-(1.2%+5)
+/-(1.2%+5)
+/-(1%+3)
+/-(1.2%+5) |
|---|
| AC Current Measurement | 400.0mA/4000mA
40.00mA/400.0mA
4.000A/10.00A | +/-(1.2%+5)
+/-(1.5%+5)
+/-(2%+5) |
|---|
| DC Current Measurement | 400.0mA/4000mA
40.00mA/400.0mA
4.000A/10.00A | +/-(1%+2)
+/-(1.2%+3)
+/-(1.5%+3) |
|---|
| Resistance Measurement | 400.0W
4.000kW/40.00kW/400.0kW
4.000MW
40.00MW | +/-(1.2%+2)
+/-(1%+2)
+/-(1.2%+2)
+/-(1.5%+2) |
|---|
| Capacitance Measurement | 40.00nF
400.0nF/4.000mF/40.00mF
400.0mF
4000mF | +/-(3%+5)
+/-(3%+5)
+/-(4%+5)
O |
|---|
| Frequency | 10Hz-10MHz | +/-(0.1%+4) |
|---|
| Frequency Response | 0 | 45~400Hz |
|---|
| Duty Cycle | 0.1%~99.9% | yes |
|---|
| Temperature Measurement(oC) | -40oC~-20oC
>-20oC~0oC
>0oC~100oC
>100oC~1000oC | -(8%+5)
+/-(1.2%+4)
+/-(1.2%+3)
+/-(2.5%+2) |
|---|
| Temperature Measurement(oF) | -40oF~-4oF
>-4oF~32oF
>32oF~212oF
>212oF~1832oF | -(8%+6)
+/-(1.2%+5)
+/-(1.2%+4)
+/-(2.5%+3) |
|---|
| Special Functions | | |
|---|
| Manual Ranging | | yes |
|---|
| Diode | | yes |
|---|
| EF Function | | |
|---|
| Audion | 1000ß | |
|---|
| Continuity Buzzer | | yes |
|---|
| Data Hold | | yes |
|---|
| Max/Min Mode | | yes |
|---|
| Display Backlight | | yes |
|---|
| REL | | yes |
|---|
| Sleep Mode | Around 15 Minutes | yes |
|---|
| Analogue Bar Graph | 41 | yes |
|---|
| RS232(USB) | | yes |
|---|
| Fuse | | yes |
|---|
| Input Impedance for DC Voltage Measurement | Around 10MW | yes |
|---|
| Low Battery Display | <7.5V | v |
|---|
