Features:

1, Suitable for LED lamp beads repairing, size of micro LED components not less than 0.6*0.6mm can be repaired
2, Suitable for LED lamp beads of tape packaging and bulk materials, Also any BGA and components which are difficult to repair.
3, High solution optical alignment system, accurate LED components positioning, ensure precise mounting.
4, Optical alignment is controlled electrically, can rotate automatically
5, Mounting head built-in pressure testing device, to protect the PCB.
6, Built-in infrared laser positioning, Fast positioning for PCB.
7, Adopt HIWIN precision guide rail for up and down movement system, ensure reliable and accurate running
8, Adopt up and down alignment for top and bottom heater, focus on heating some part, prevent PCB to turn yellow.
9, Bottom heater up and down manually, can adjust the heating height any time.
10, Adopt ceramics infrared radiator for IR heater, heating stably and uniformly with long serve life
11, Human-machine interface has multiple operation mode and permission, welding, desolder and mounting manually, easy operation.
12, High resolution touch screen, which is up to 800*600 pixel.
13, Adopt joystick control for alignment system, no need setting complicated parameters.
14, Adopt Delta double ball bearing flow fan for air supply?no need external air source.
15, Adopt DCCE 6 channel module for temperature control system, automatic PID adjustment.
16, Monitoring heaters real time, when accident happens, relevant sensors will send signal to PLC, which will close output channel and display fault condition. Protect it automatically.

Specification:

Total Power: Max 5300W
Power: AC 220V±10%   50/60 Hz
Top heater power: 1200W
Bottom heater power: 1200W
IR power: 2700W
Hot air temperature: 400? (Max)
Preheating temperature: 400??Max?
Positioning: V-groove +laser positioning +universal fixture
PCB size: Max 410×370 mm
Preheating size: 370mm×270mm
Chip type: BGA, QGN, CSP, POP, QFN, Micro SMD, LED lamp beads
Chip size: Max 80×80mm   Min 2×2 mm
Dimensions: L640×W630×H900 mm
Temperature sensor: 1 piece
Net weight: 70k
Color: White
