50ton Zoomlion Mobile Truck Crane Qy50V532

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Pieces)	Unit Price
1.0	US $ 1000/ Piece

Price:US $1000.0 / Piece

Trade Terms: FOB, CFR, CIF, FAS, DDP, DAP, CIP, CPT, FCA, EXW

Payment Terms: L/C, T/T, D/P, Paypal

Price Valid Time:From Jun 10, 2015 To Sep 10, 2018

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description
Additional Information
Reviews

Description

Details

Basic Info.

Model NO.:QY50V532

Type:Truck Crane

Application:Construction Usage

Sling Type:Cable

Power Source:Hydraulic

Certification:ISO9001: 2000

Condition:New

Payload:50ton

Brand:Zoomlion

Export Markets:Global

Additional Info.

Trademark:ZOOMLION

Packing:Nude Package

Origin:Xuzhou, China

Production Capacity:50 Sets/Month

Product Description

50ton Zoomlion mobile truck crane QY50V532

QY50V532 truck crane, which is developed independently to adapt to the market demands, is a new-generation and high-performance product integrating our company many years' manufacturing experience with advanced technologies. Its performances such as lifting height, boom length, working speed and lifting capacity have achieved advanced international level.

The truck crane, with spacious cab and luxurious equipments, adopts full slewing system, telescopic boom, hydraulic proportional control system and self-made full-width special purpose chassis with four axles. 8× 4 drive and hydraulic power steering mechanism provides the crane with good driving performance and flexible steering.

The system with latest load feedback hydraulic operated proportional directional control valve and quadruple gear pump, and the safety devices fitted in hydraulic system, such as relief valve, balance valve, hydraulic lock and brake valve etc., prevents the oil line from overloading and the accidents caused by oil pipe breakage to makes full use of the working capacity of each actuating mechanism. Thus the reliability and safety of the crane are increased.

The safety devices such as load moment limiter, and the complete lighting system equipped in the crane ensure your safety during operation and are convenient for night work.

Item			Value	Remarks
Working performance specification	Max. rated total lifting capacity kg		50000
	Max. load moment of basic boom kN. m		1764	1470(Outrigger beam half extended)
	Max. load moment with max. main boom length kN. m		940.8	793.8(Outrigger beam half extended)
	Max. lifting height of basic boom m		11.6
	Max. lifting height of main boom m		42.1	Deformation of boom is not taken into consideration
	Max. lifting height of fly jib m		58.3
Working speed	Max. speed of single rope on main winch m/min		130	The 4 th layer of drum
	Max. speed of single rope onauxiliary winch m/min		72	The 2 nd layer of drum
	Derricking time of boom s		50
	Telescopic time of boom s		95
	Slewing speed r/min		0~2
Traveling specification	Max. traveling speed km/h		76
	Max. gradeability %		32
	Min. turning circle diameter m		24
	Min. ground clearance mm		260
	Limits for exhaust pollutants and smoke		Comply with related standards	GB3847-2005 GB17691-2005 (StageIII)
	Oil consumption per hundred kilometers L		48
Mass specification	Deadweight of crane in traveling condition kg		41000
	Complete vehicle kerb mass kg		40470
	Front axle load kg		17200
	Rear axle load kg		23800
Dimension specification	Overall dimensions(L× W× H)mm mm		13300× 2750× 3650
	Base on outriggers m		5.92
	Distance between outriggers m		6.90
	Main boom length m		11.1-42.0
	Main boom angle°		-2-80
	Fly jib length m		9.5, 16
	Offset angle of fly jib °		0, 30
Chassis	Model		ZLJ5414
	Class		II
	Engine	Model	WP10.336	QSL 325
		Rated power KW/r/min	247/2200	242/2200
		Max. output torque N. m/r/min	1250/1200-1600	1424/1500
