Description

Details

Basic Info.

Model NO.:YLM-B

Voltage:380V

Rated Pressure:45MPa

System Pressure:63MPa

Export Markets:Global

Additional Info.

Trademark:Haolida

Packing:Export Plywood Case

Standard:ISO

Origin:China, Shandong

HS Code:8463900090

Production Capacity:50PCS Per Month

Product Description

YLM-B Model Cold rivet machine for truck crossbeam,lifting lug
1.Function Introduction
Cold rivet machine for truck crossbeam,lifting lugis supplied oil by means of extra high pressure plunger pump and is set limit pressure protection device.
Cold rivet machine for truck crossbeam,lifting lug uses electric and hand-control equipment so that operation is more convenient.
Cold rivet machine for truck crossbeam,lifting lugruns stably and can be moved at random with large riveting force, strong applicability and used widely for riveting various metals.
Riveting machine for truck crossbeam,lifting lug is used mainly for cold riveting of crossbeam and lifting lug in the industry of modifying, manufacturing and maintaining automobiles.
2.Technical Parameter
   Maximum cold riveting force is below ?16.
    Practical power: 380V
    Rated pressure: 45MPA
    System pressure: 63MPA
    Riveting bow can be customized according to the demands of customers.
3. Technical Parameters of Riveting Bow

Model	Cold diameter	Hot diameter	Stroke of oil cylinder	L1	L2
Large	16 mm	20 mm	150	260	280
Medium	14 mm	16 mm	150	200	180
Small	12 mm	14 mm	150	160	130
