| Detailed Configurations: (" S" stands for Standard configuration and " O" stands for Optional configuration) |
|
|
|
|
| Body and Frame |
|
|
|
|
|
|
|
|
|
| Frame | Welded steel framework with phosphate+electro-coating treatment |
|
|
|
|
|
| Body | PP plastic front body + PP plastic rear body |
|
|
|
|
| S |
| Roof | injected plastic |
|
|
|
|
|
|
| S |
| Windshield | one-piece Organic glass |
|
|
|
|
|
| S |
| Windshield, hinged |
|
|
|
|
|
|
| O |
| Laminated windshield |
|
|
|
|
|
| O |
| Laminated windshield with wiper |
|
|
|
|
|
| O |
| Stainless steel package | including front upright, rear upright, sweater basket and bracket |
|
|
|
| O |
| Aluminum roof support | including front upright, rear upright, caddie handle |
|
|
|
|
| O |
| 2point seat belt | \ |
|
|
|
|
|
|
| O |
| Large Seats: |
|
|
|
|
|
|
|
|
|
| 1) backrest and cushion | Rebond seat + artificial leather |
|
|
|
|
|
| S |
| 2) armrest | Formed |
|
|
|
|
|
|
| S |
| 3) plastic seat bottom | \ |
|
|
|
|
|
|
| S |
| Formed seat& backrest vinyl | \ |
|
|
| O |
| Backrest cover in wood finish | \ |
|
|
|
|
|
|
| O |
| Floor | rubber |
|
|
|
|
|
|
| S |
| Center storage basket | Large volume |
|
|
|
|
|
|
| S |
| Golf bag holder | \ |
|
|
|
|
|
|
| S |
| Dashboard in black plastic | forward/reverse switch, battery capacity indicator, ignition key |
|
|
|
| S |
| Dashboard in wood finish | \ |
|
|
|
|
|
|
| O |
| Steering wheel in wood finish | \ |
|
|
|
|
|
|
| O |
| Beverage holders | 4 cups drink holders |
|
|
|
|
|
| S |
| Glove box | \ |
|
|
|
|
|
|
| S |
| Glove box door (include two locks) in black plastic | 2 doors per set |
|
|
| O |
| Glove box door (include two locks) in wood finish (inside and outside) | 2 doors per set |
|
|
| O |
| Side trim | Aluminum |
|
|
| S |
| Score card holder | on steering wheel |
|
|
|
|
|
|
| S |
| Towing bracket | on front of golf car |
|
|
|
|
|
|
| S |
| Inner rear view mirror | 1 piece per cart in the middle of the windshield |
|
|
|
|
| O |
| Side rear view mirror | Two pieces per cart |
|
|
|
|
|
|
| O |
| Battery watering system, 48V system | without water supply tool |
|
|
| O |
| Battery watering system, 36V system | without water supply tool |
|
|
| O |
| Manual Pump | water supply tool (other water supply tools are available) |
|
|
| O |
| Enclosure | \ |
|
|
|
|
|
|
| O |
| Electric system |
|
| Lighting system and horn | 2 headlights, 2 front turn signals, 2 taillights( each combined 1 brake light with 1 turn signal), with DC-DC converter (converting from 48V to 12V), horn. | S |
| Reversing alarm | \ | S |
| Meter(only available for 48V system) | speed, mileage, headlight indicator, emergency light indicator, turn signal indicator, reverse indicator |
| O |
| Police Light |
| O |
| 12V accessory plug | to be mounted on the dashboard | O |
| Hour meter | \ | O |
| Solar Panel | 48V, 185W | O |
| Cooler | 12V DC, 6L | O |
| Charger | China origin, input 110V-240V~50Hz-60Hz, output 36V/48V, 25A | S |
| Steering and Suspension |
|
| Steering system | Single-stage rack and pinion steering system, automatic rocker compensating function | S |
| Right hand drive system | \ |
|
|
|
|
|
|
| O |
| Brake system | Mechanical brake | S |
| 4-wheel hydraulic brake + hand brake | O |
| 4-wheel hydraulic brake, front disc brake, rear drum brake | O |
| Accelerator | Stepless speed change | S |
| Suspension system | Front and rear plate spring + cylinder hydraulic shock absorber | S |
| Driving mode | Rear axle two stage deceleration, motor direct driving | S |
| Rear axle | Integrated, Gear ratio 12.76: 1 |
|
|
|
|
|
| S |
| Integrated, Gear ratio 10.26: 1 |
|
|
|
|
|
| O |
| Wheel & Tyre | 10x6 Alumimum wheel & 205/50-10 4PR | S |
| 6J-10 steel wheel with cap & 205/50-10 4PR | O |
| 8*7 steel wheel with cap & 18*8.5-8 4PR | O |
