High Quality Electric Hydraulic Truck Pit Lift

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Pieces)	Unit Price
1.0	US $ 1/ Piece

Price:US $1.0 / Piece

Trade Terms: FOB, CFR, CIF

Payment Terms: T/T, Western Union

Price Valid Time:From Jul 25, 2015 To Dec 31, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:DXJ

Type:Hydraulic Jack

Structure:Hydraulic Jack

Capacity (Load):11-20T

Power Source:Electric

Max Height:>400mm

Certification:ISO 9001:2008

Condition:New

Max Lifting Tons:15t

Max Working Stroke:630mm

Using Way:Pit Use

Name:High Quality Electric Hydraulic Truck Pit Lift

Export Markets:Global

Additional Info.

Trademark:Haolida

Packing:Export Plywood Case

Standard:ISO9001

Origin:Shandong, China

HS Code:8425429000

Production Capacity:200sets Per Month

Product Description

High Quality Electric Hydraulic Truck Pit Lift

General introduction
It is a technical automobile lift, suspensioned on the trench.

Advantages:

1.It is used on the trench.
2.Hydraulic drive and stable lift;
3.Insured pin;
4.With quick falling handle;
5.Longitudinally move the cushion for positioning;
6.Lateral movement with manual locking positioning;
7.Equipped with all special brackets according to the requirements of users;
8.It can be made according to size of the trench (width and height);
9.It is easy and saft to operate

Technical parameter:

Model no	DXJ
Color	Blue
Max lifting weight	150KN(15T)
Maximum lifting height	800mm
Minimum height (away from the surface of guide ways)	170mm
Working stroke	630mm
Applicable clearance (Inner distance of guide ways)	950~1050mm
Motor power	2.2KW
Working voltage	AC 380V
Accessories:
support tools,etc
Others you may want to know:
MOQ	1set
Warranty period	12 months
Payment term	T/T 50% in advance, the balance should be paid before delivery (negotiable)
Delivery time	20 days after receiving downpayment
HS code	8425429000
Packing size	Export plywood case 10408401240mm=1.08CBM N.W:250KGS G.W: 300KGS

Why Choose us:

1.32 years' design,development and produce experience
2.Professional R&D team
3.Strict QC
4.A good pre-sale and after-sale service
5.Can design and make according to customer's requests
