Price Zoomlion 50ton Mobile Truck Crane QY50V532

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Pieces)	Unit Price
1.0	US $ 10/ Piece

Price:US $10.0 / Piece

Trade Terms: FOB, CFR, CIF, DAT, FAS, DDP, DAP, CIP, CPT, FCA, EXW

Payment Terms: L/C, T/T, D/P, Paypal, Money Gram, Western Union

Price Valid Time:From Nov 23, 2014 To Jan 24, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description
Additional Information
Reviews

Description

Details

Basic Info.

Model NO.:QY50V532

Type:Small Crane

Application:Construction Usage, Workshop Usage, Container Usage, Mineral Area Usage

Tower Crane Type:Under Slewing Cranes

Sling Type:Wire Rope

Main Girder Form:Double Girder

Power Source:Electric

Moving Type:Orbital

Installation:Assembled

Certification:ISO9001: 2000, CE

Condition:New

Rated Lifting Capacity: 50ton:6*4 Drive

Export Markets:Global

Additional Info.

Trademark:ZOOMLION

Packing:Suitable for Ocean Shipment

Standard:ISO

Origin:China

Production Capacity:1000 Unit/Year

Product Description

Price Zoomlion 50ton mobile truck crane QY50V532

1. Rated lifting capacity: 50ton
2.5-section telescopic boom sections, 6*4 drive

Price Zoomlion 50ton mobile truck crane QY50V532

1. Rated lifting capacity: 50ton
2.5-section telescopic boom sections, 6*4 drive

Price Zoomlion 50ton mobile truck crane QY50V532

1. Rated lifting capacity: 50ton
2.5-section telescopic boom sections, 6*4 drive

Item			Value	Remarks
Working performance specification	Max. rated total lifting capacity kg		50000
	Max. load moment of basic boom kN.m		1764	1470(Outrigger beam half extended)
	Max. load moment with max. main boom length kN.m		940.8	793.8(Outrigger beam half extended)
	Max. lifting height of basic boom m		11.6
	Max. lifting height of main boom m		42.1	Deformation of boom is not taken into consideration
	Max. lifting height of fly jib m		58.3
Working speed	Max. speed of single rope on main winch m/min		130	The 4 th layer of drum
	Max. speed of single rope onauxiliary winch m/min		72	The 2 nd layer of drum
	Derricking time of boom s		50
	Telescopic time of boom s		95
	Slewing speed r/min		0~2
Traveling specification	Max. traveling speed km/h		76
	Max. gradeability %		32
	Min. turning circle diameter m		24
	Min. ground clearance mm		260
	Limits for exhaust pollutants and smoke		Comply with related standards	GB3847-2005 GB17691-2005 (Stage3)
	Oil consumption per hundred kilometers L		48
Mass specification	Deadweight of crane in traveling condition kg		41000
	Complete vehicle kerb mass kg		40470
	Front axle load kg		17200
	Rear axle load kg		23800
Dimension specification	Overall dimensions(L×W×H)mm mm		13300×2750×3650
	Base on outriggers m		5.92
	Distance between outriggers m		6.90
	Main boom length m		11.1~42.0
	Main boom angle°		-2~80
	Fly jib length m		9.5, 16
	Offset angle of fly jib °		0 , 30
Chassis	Model		ZLJ5414
	Class		2
	Engine	Model	WP10.336	QSL 325
		Rated power KW/r/min	247/2200	242/2200
		Max. output torque N.m/r/min	1250/1200~1600	1424/1500
