XCMG Construction Vehicle, 160t All Terrain Truck Crane Qay160

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Pieces)	Unit Price
1.0	US $ 1/ Piece

Price:US $1.0 / Piece

Trade Terms: FOB, CFR, CIF, DAT, FAS, DAP, CIP, CPT, EXW

Payment Terms: L/C, T/T, Paypal, Money Gram, Western Union

Price Valid Time:From Jun 01, 2015 To Aug 29, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:Qay160

Model No.:Qay160

Type:Single Girder Crane

Application:Construction Usage, Workshop Usage, Container Usag

Power Source:Hydraulic

Sling Type:Wire Rope

Certification:ISO9001: 2000, CE

Max Load Moment:160t

Gradeability:40%

Export Markets:Global

Additional Info.

Trademark:XCMG

Packing:Nude

Standard:CE, RoHS, SGS, GMP

Origin:Jaingsu China

HS Code:84295100

Production Capacity:50, 000 PCS/Year.

Product Description

Features:

QAY160 new terrain crane integrates 222 patent techniques, adopts 38 new patents techniques, and shows 8 technical highlights.
The overall length in travel is only 15.77m, the weight is 60t, the chassis length is 13.77m, and the minimum turning radius is 10m. The whole configuration includes 6-segment boom with the length of 62m and 3-segment jib with the length of 28m. 6 counterweight combinations can finish nearly 30000 working conditions.
Adopt the imported Benz EFI engine with strong power system and imported 12-gear automatic control transmission. The 2nd, 4th, and 5th axles are the drive axle. The steering form is 10x10 full-axle steering.
Adopt new single cylinder retractable technique and high-intensity imported steel, featuring lighter dead-weight and stronger performance.
The self-combination counterweight technique developed by ourselves can effectively improve the lifting performance by 30%.
The electrohydraulic proportion control multi-axle steering mode can realize many kinds of steering modes.
The new brake technique can reduce 2/3 maintenance cost, and improve the travel safety.
The comfortable cabs and outrigger operation completely show the humanity design concept.
Equip with the XCMG unique control system, auxiliary retractable boom system, virtual wall system, perfect failure diagnosis, real-time detection, CAN technique, etc.

Techncial Paramters

Classificatory	Item		Unit	Parameter
Dimension	Overall length		mm	15900
	Overall width		mm	3000
	Overall height		mm	4000
	Wheel base	Axle 1, Axle 2	mm	2750
		Axle 2,Axle 3,Axle 4,Axle 5, Axle 6	mm	1650
		Axle 3, axle 4	mm	2000
	Track		mm	2590
Mass	Total mass in travel state		kg	70900
	Axle load	Axle 1, Axle 2	kg	11635
		Axle 3, Axle 4	kg	11815
		Axle 5, Axle 6	kg	12000
Power	Crane superstructure engine	Rated power	kW/(r/min)	162/2100
		Rated torque	N.m/(r/min)	854/1400
		Rated speed	r/min	2100
	Crane carrier engine	Rated power	kW/(r/min)	380/1800
		Rated torque	N.m/(r/min)	2400/1200
		Rated speed	r/min	2000
Travel performance	Travel speed	Max. travel speed	km/h	71
	Travel speed	Min. stable travel speed	km/h	2.1
	Min. turning diameter		m	24
	Min. ground clearance		mm	278
	Approach angle		°	25
	Departure angle		°	20
	Braking distance (at 30km/h with full load)		m	? 10
	Max. grade-ability		%	48
	Fuel consumption for 100km		l	80

Technical Data for Lifting Operation

Classificatory	Item			Unit	Parameter
Main performance	Max. total rated lifting capacity			t	160
	Min. rated working radius			m	3
	Turning radius at turntable tail			mm	4850
	Max. load moment	Base boom		kN.m	5282
		Fully extended boom		kN.m	2140
	Outrigger span	Longitudinal		m	9.625
		Lateral		m	8.7(6.5)
	Lifting height	Base boom		m	14.3
		Fully extended boom		m	56.3
		Fully extended boom + Jib		m	79
	Boom length	Base boom		m	13.6
		Fully extended boom		m	60
		Fully extended boom + Jib		m	80
	Jib offset			°	0,15,30
Working speed	Boom elevating time	Boom raising		s	90
	Boom telescoping time	Boom full extension		s	600
		Boom full retraction		s	600
	Max. swing speed			r/min	2
	Hoist speed (single rope at 4th layer)	Main winch	No load	m/min	120
		Aux. winch	No load	m/min	110
	Crane exterior noise			db(A)	?118
	At seated position			db(A)	?90
