Alvanized steel floor deck
High strength
Easy installation
Stable and reliable quality
Long useful life: More than 25 years
1. Definition:
Corrugated galvanized steel sheet (The floor steel deck) is the permanent upholding slab used in the steel structure buildings, formed by zinc-coating steel sheet to be rolled and cold bended. It is both the permanent upholding slab, working together with the cast-in-situ concrete layer, and permanent component of buildings. After molding, it can be divided into closed type, open type and necking type.
Galvanied steel floor deck is a sort of key product matching the cnstructions of steel structure. Our company has many products lines of steel plates. The product features advanced patterns, completes spercifiactions, attractives prices, absolute superiority and serverd mainly for multi and high tired buildings made of steel structure.
2. Specialties and advantages:
(1) Light weight, high strength, good bearing performance, good anti-seismic performance
(2) Easy and quick construction, simple assembled
(3) To replace the traditional templates and improve shortcomings of traditional templates
(4) As part of the structural strength to reduce the material cost
(5) Easy reinforcement, wiring, piping construction
(6) Neat and nice looking
3. Use:
The products are widely used in steel structure buildings, such as multi-layer and high-rise steel structure housing, power plants, exhibition centers, the airports, railway stations, sports stadiums, concert halls, theatres, large supermarkets, logistics centers and Olympic venues.
4. Description:
The thickness ranges from 0.7mm to 3.0mm, and the material can be Q235, Q345 or Q410.
Wave height: 51mm
Pitch of wave: 250mm
Effective width: 750mm
Coil (unfolding) width: 1000mm
Product
Product Name
Corrugated metal roofing sheet
Component
Basic Steel Sheet + Hot Dipped Galvanized Zinc + Color Coat (yes or no)
Material
SGCC
Zinc Coating
60-2750g/m2
Spangle
Regular, big, small, or spangle-free
Color Coating Material
PE, SMP, HDP, PVDF
Color
Any according to your request
Total Thickness
0.15 -1.0mm
Shape to Cover
Any, flat or achy
Fluted Profile
More suitable and flexible than flat sheet
Surface Shape
With flutes horizontal or vertical
Application
Building Material for roof and wall
Characsristic
Easy installation, less maintenance, high strength, and low cost
Recyclable
Can be disassembled and installed again
Safe
Earthquake resistan
Quality Level:
Standard
Certificate
ISO9001: 2008
What different between PVDF and PE coating?
PVDF is the most advanced painting in co
