| Basic Functions | Range | Best Accuracy |
|---|
| DC Voltage Measurement | 220.00mV
2.2000V22.000V220.00V
1000.0V | +/-(0.1%+5)
+/-(0.1%+2)
+/-(0.1%+5) |
|---|
| AC Voltage Measurement | 6
220.00mV
2.2000V
22.000V
220.00V
750V | 45~1kHz >1kHz~10kHz
+/-(1%+10) +/-(1.5%+30)
+/-(0.8%+10) +/-(1.2%+50)
+/-(0.8%+10) +/-(0.8%+50)
+/-(0.8%+10) +/-(2.0%+30)
+/-(1.2%+10) +/-(3.0%+30) |
|---|
| AC Current Measurement | 220.00mA/2200.0mA
22.000mA/220.00mA
2.2000A/10.000A | +/-(0.8%+10) +/-(1.2%+30)
+/-(1.2%+10) +/-(1.5%+30)
+/-(1.5%+10) +/-(2.0%+30) |
|---|
| DC Current Measurement | 220.00mA/2200.0mA
22.000mA/220.00mA
2.2000A/10.000A | +/-(0.5%+10)
+/-(0.5%+10)
+/-(1.2%+50) |
|---|
| Resistance Measurement | 220.00W/2.2000KW
22.000kW/220.00kW
2.2000MW
22.000MW
220.00MW | +/-(0.5%+10)
+/-(0.5%+10)
+/-(0.8%+10)
+/-(1.5%+10)
+/-(3%+50) |
|---|
| Capacitance Measurement | 22.000nF
220.00nF/2.2000mF/22.000mF
220.00mF/2.2000mF
22.000mF/220.00mF | +/-(3%+5)
+/-(3%+5)
+/-(4%+5)
Only reference |
|---|
| Frequency | 10Hz-10MHz | +/-(0.1%+4) |
|---|
| Duty Cycle | 0.1%~99.9% | yes |
|---|
| Special Functions | | |
|---|
| Manual Ranging | | yes |
|---|
| RS232(USB) | | yes |
|---|
| Diode | | yes |
|---|
| Ture RMS | | yes |
|---|
| Continuity Buzzer | | yes |
|---|
| Data Hold | | yes |
|---|
| Analogue Bar Graph | 61 | yes |
|---|
| REL | | yes |
|---|
| Peak | | yes |
|---|
| Fuse | | yes |
|---|
| Input Impedance for DC Voltage Measurement | Around 10MW | yes |
|---|
| Low Battery Display | <7.5V | yes |
|---|
