Home GSM SMS Alarm Password Protection Intruder Alarm System with Sos Button

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Price:

Min. order:200 Pieces

Trade Terms:FOB

Payment Terms:T/T

Trademark:Cayera

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:AM-F2

Type:Anti-Theft Alarm

Signal Transmission:Wireless Alarm

Working Mode:Active

Certification:CE, ISO, FCC, RoHS

Application:Indoor

Sensor Type:Infrared Alarm System

Working Principle:Electro-Optical Type

Transmission Mode:Wireless

Alarm Volume (within 1m):?80dB

Receive Frequency:433.92MHz

Usage:Door, Personal, Auto, Window, Fire, Smoke

Alarm Response Time:Less Than 8s (GSM Signal in No

Size:187mm(L)X130mm(W)X27mm(H)

Working Consumption:Less Than 0.6W

GSM Frequency:850/900/1800/1900MHz

SMS Command for Remote:No Distance Limit

Export Markets:Global

Additional Info.

Trademark:Cayera

Standard:CE, FCC, ROHS

Origin:Shenzhen, China

Production Capacity:50000 PCS/Year

Product Description

Features:

1. Built-in Siren
AM-F2 comes with internal siren, user can D.I.Y to setup the sirn's alarming time beween 0 to 254s
2. 24 Wireless Alarm Zones
AM-F2 comes with 24 wireless alarm zones, 6 fire alarm zones and 2 wired alarm zones,
user ca add additional sensors to each of these zones as their mind. It is able to program 20 remote controllers or panic buttons for the necessary
3. Direct Phone Call
Through the touch keypad on the main panel, users can setup alarm phone numbers,
and inquiry balance money of the SIM card in alarm panel, yo can make phone calls
directly and do all the operations for the system
4. Setup 3 numbers for SMS, 3 numbers for calling
5. 24 wireless zones, 6 fire alarm zones, 6 panic buttons, 2 wired zones and 14
remote controllers
6. Touch keypad on alarm panel enable to arm/disarm/home mode
7. Two-way communication
8. Enable control the alarm via SMS and phone keypad

Specification

Specification
Wireless frequency	15MHz/433MHz
GSM frequency	850/900/1800/1900MHz
Alarm response time	Less than8s (GSM signal in normal)
Power requirements	Input: AC 220V 50Hz/60Hz Output: DC 12V/1A Working consumption:Less than 0.6W Backup battery: DC7.4V/850MA Backup battery working hours: more than10 hours
Working condition	Temperature: -20~+55ºC humidity: ?90%
Size	187mm(L)×130mm(W)×27mm(H)
Record time	10s
Weight	0.36kg
