HOWO A7 Sino 8X4 336HP 45m3 Cargo Truck

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Pieces)	Unit Price
1.0	US $ 30000.0-50000.0/ Piece

Price:$30000.0 - $50000.0 / Piece

Trade Terms: FOB

Payment Terms: L/C, T/T, Western Union, CASH

Price Valid Time:From May 29, 2015 To Aug 29, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:HOWO A7 Cargo Truck

Type:Light Truck

Transmission Type:Manual

Emission Standard:Euro 2

Load Capacity:25t

Power:Diesel

Drive Wheel:4WD

Seats:?5

Horsepower:150-250hp

Engine Capacity:6-8L

Tire Type:Inner Tube

Tire Certification:ISO

Tire Design:Radial

Condition:New

Truck Type:Cargo Truck

Wheel Base (Mm):4600

Wheel Tread (Front/Rear, Mm):2022/1830

Model:Zz1167m4611W

Export Markets:North America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe

Additional Info.

Trademark:HOWO A7

Packing:in Bulk

Standard:CCC

Origin:China

HS Code:8704190000

Production Capacity:20000 Units Per Year

Product Description

HOWO A7 CARGO TRUCK

1. Driving type: 4x2, 6x2, 6x4 and 8x4. There are two types for 6x2: Twin steering axles and middle lifting axle.

2. Cab: Mainly HW76 lengthened and HW79 high roof.

3. Engine: EURO2 and EURO3. Power options: 266PS, 290PS, 325PS, 336PS, 371PS and 375PS.

4. Wheelbase (mm)
4x2: 4600, 5000, 5600
6x2: 1800+5000(twin steering), 1800+5600(twin steering), 5825+1350(twin steering)
6x4: 4325+1350, 4300+1400, 4600+1350, 4575+1400, 5225+1350, 5200+1400, 5825+1350, 5800+1400
8x4: 1800+3800+1350, 1800+3775+1400, 1800+4600+1350, 1800+4575+1400

5. GVW(t): 16(19), 25(32), 31(38, 40).

Product	HOWO 4x2 cargo truck		Model	ZZ1167M4611W
Dimension	Overall dimension (mm) LWH			837724963048

	Cargo body dimension (mm) LWH			55502326600

	Cargo body capacity (m3)			7.8
	Wheel base (mm)			4600
	Wheel tread (front/rear, mm)			2022/1830
	Overhang (front/rear, mm)			1500/2277
	Approach/departure angle (°)			23/15
Weight	Gross vehicle weight(kg)			7860 (chassis 6950)
	Pay load (kg)			8010
	Overall weight (kg)			16000
Max. speed (km/h)	102
Chassis	Number of axles			2
	Tire			12.00R20
	Number of tires			6+1
Cab	Model			HW 76 lengthened, 2 seats, 1 bed
	Air conditioner			optional
Engine	Type			In-line, 6 cylinder, water-cooling, turbo-charging, EFI, diesel

	Model			WD615.62
	Displacement (ml)			9726
	Rated power (hp/rpm)			266/2200
	Peak torque (N.m/rpm)
	Emission standard			Euro 2
Clutch	Model
	Type			Single, dry plate
Gear box	Model
	Type			manual
	Forward gears
	Ratio


Steering	Model			ZF 8098
	Type			Integral power steering
Front axle	Model			HF 7 hub
	Loading capacity			7000
Rear axle	Model			HW 1667
	Loading capacity			13000

	Ratio			4.875
Braking system	Service brake			Dual circuit compressed air brake
	Parking brake (emergency brake)			Spring energy, compressed air operating on rear wheels
	Auxiliary brake			Engine exhaust brake
	Option			ABS
Suspension	Front	Type		Non-independent
		Number of leaf spring
	Rear	Type		Non-independent
		Number of leaf spring
