Vehicle Beiben Concrete Truck Mixer Heavy Truck

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Price:

Min. order:1 Piece

Trade Terms:FOB

Payment Terms:L/C, T/T

Trademark:Truemax

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description
Additional Information
Reviews

Description

Details

Basic Info.

Model NO.:CTM12/5

Vehicle:Dongfeng,Beiben,Sino

Export Markets:Global

Additional Info.

Trademark:Truemax

Standard:ISO9001: 2000 and CE CERTIFICAT

Origin:China

HS Code:8479109000

Production Capacity:10 Units/Month

Product Description

Multi Types of Chassis Match

1.The upper can match with different Chassis of 2, 3 or 4 axles

2.The upper can be designed to match with different Chassis as requirement.

Mixing Drum Structure

1.The drum body and blades are made by quality wearable exclusive steel plate with light weight of BaosteelB520JJ. And the drum is suit for transport both dry and wet materials.

2.The surface welding adopt manipulator double welding enables the strength structure and long service life.

3.Double pitch special designed blades ensure the fully mixing inside and low discharge surplus rate

4.Unique design of agitator inclined angle with the whole drum make the lower and stable center of gravity this makes the ,driving more steady and discharging more smooth, and gains better traffic ability.

5.The drum frame assembly adopt the flexible connection and reinforcing design. It ensures the load strength and safety driving.

Hydraulic System

1.Closed circuit hydraulic system and constant hydraulic oil temperature controller

2.Adopt world famous brand hydraulic pump, hydraulic motor,reducer and radiator. Also provide multi options for different requirement.

Water Supply

1.Pneumatic water supply system with large water tank which can wash different points including agitator drum, charging hopper and discharging hopper respectively

2.Rational layout and elegant appearance of washing pipes make the washing more convenient and rapid.

SPECIFICATIONS	7M³	9M³	10M³
Geometric volume of drum(m³)	11.3	14.91	16.2
Mixing capacity(m³)	7	9.64	10
Material of blades/drum	Q345MN	Q345MN	B520JJ
Inclination angle for drum(@)	15	12	13
Padding rate(%)	61.94%	64.65%	63%
Residual rate(%)	<0.16%	<0.16%	<1%
Charging speed(m³/min)	?3	?3	?3
Discharging speed(m³/min)	?1.2	?1.2	?2
Mixing speed(r/min)	50-220	0-14	70-260
Capacity for water tank(\|)	350	350	350
Air pressure(mpa)	0.4	0.4	0.4
Max.External diameter of drum(mm)	2118	2342	2432
Length of the drum(mm)	3868	4764	4811
A Upper-fixing Length(mm)	5930	6600	6685
B Subframe Length(mm)	5090	5760	5575
C Chute Position(mm)	840	840	850
D Center of Gravity when Fully Load(mm)	2385	2695	2750
E Hopper Height(mm)	2500	2570	2660
F Upper-fixing Height(mm)	2565	2635	2785
Overall dimension(LWH/mm)	593024902565	660024902635	668524902785
Weight(Kg)	3900	4500	5000
Water supple	Air pressure	Air pressure	Air pressure
