XCMG 20 Ton Mobile Truck Crane (QY20G)

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Pieces)	Unit Price
1.0	US $ 88888/ Piece

Price:US $88888.0 / Piece

Trade Terms: FOB, CFR, CIF

Payment Terms: L/C, T/T, Western Union

Price Valid Time:From Nov 23, 2014 To Feb 21, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:QY20G

Type:Small Crane

Application:Construction Usage

Sling Type:Cable

Power Source:Hydraulic

Certification:ISO9001: 2000

Condition:New

Color:Gloden Yellow

Export Markets:Global

Additional Info.

Trademark:XCMG

Packing:Suitable Package for Shipment

Standard:40FR

Origin:Jiangsu China

HS Code:87051092

Production Capacity:100/Month

Product Description

XCMG Mobile truck crane QY20G
1) Lifting Capacity: 20ton
2) Engine rated power: 196/2200kw/(r/min)
3) Base boom: 833KN. M

1. Specialized boom of Bi-hexagonal cross section optimized, local stability of web and side plate, and lifting boom stability are better than the similar products made by the same industry manufacturers.

2. Built-in boom head, larger slider supporting area, better stress distribution, longer lifetime; Strong restriction of slider to boom body reduces the boom torsion and side-bending, accordingly safety of operating boom is improved.

3. Full-dimension driver's cab, spacious and comfortable for operator to operate. Full covered walking surface is available.

4. The 5Th jack is standard, 360° Operation of boom is available.

5. Excellent welding technology for structural members. Welding robot with advance process used for key welding make reliable quality products.

6. Ferrule-type compression joints are used for pipeline, have features of reliable connection, better tightness and less leakage.

Category	Item			Unit		Parameter
Outline Dimensions	Overall length			mm		12000
	Overall width			mm		2500
	Overall height			mm		3320
	Wheel base			mm		4425+1350
	Track			mm		2074/1834/1834
Weight	Total vehicle mass in travel configuration			kg		26020
	Axle load	Front axle	kg		6990
		Rear axle	kg		19030
Power	Model					SC8DK260Q3
	Engine rated power			kw/(r/min)		192/2200
	Engine rated torque			N. m/(r/min)		1100/1400
Travel Performance	Max. travel speed			km/h		75
	Min. turning diameter			m		20
	Min. ground clearance			mm		275
	Max. grade ability			%		24
	Approach angle			°		16
	Departure angle			°		13
	Braking distance (at 30 km/h, full load )			m		10
	Oil consumption per 100km			L		35
Noise	Exterior noise level during acceleration traveling			dB (A)		84
	Noise level at seated position			dB (A)		90
